Extralink Adele | Fiber optic terminal box | 2 core

CODE: EX.0707 / EAN: 5902560360707

Extralink Adele | Fiber optic terminal box | 2 core

CODE: EX.0707 / EAN: 5902560360707
2,11 USD without VAT (net)
Out of stock
Mast mountable: No
Number of fibres supported (max): 2
Number of splice trays supported (max): 1
Show more parameters

About product

EXTRALINK ADELE 2 CORE: Optical fibre closure

The ADELE 2 CORE fiber optic closure is used to connect and terminate internal fiber optic cables with pigtails. It is mounted on walls or in stationary installations. It has 2 outputs.

adele 2 core fiber optic box

Features:

  • Removable front flap, dust-proof
  • Suitable for many types of modules used in fibre optic networks
  • Easy to assemble and disassemble
  • Fibre optic adapters SC Simplex or Duplex LC can be used
extralink adele distribution box 2 core
cheap 2 core fibre optic boxes
fluorescent fibre cans

Specification

Features / filters
Housing material Acrylonitrile butadiene styrene (ABS)
Mast mountable No
Number of fibres supported (max) 2
Number of splice trays supported (max) 1
Product colour White
Suitable for indoor use Yes
Suitable for outdoor use No
Wall mountable Yes

Basic technical parameters
Scope of application 3.0 x 2.0 mm drop cable or internal cable
Fibre diameter 125µm ( 652 & 657 )
Diameter TBF 250µm & 900µm
Modes Single and multi-mode
Tensile strength 50N
Dimensions 83.4 mm * 130 mm * 24.1 mm
Maximum number of seats SC : 2
LC : 4
PLC : 4 (LC)
Operating temperature -40~+85C
2,11 USD without VAT (net)
Any customs costs and VAT are to be borne by the buyer in the country of receipt.
Out of stock
