TP-Link TL-ER6120 | Router | 5x RJ45 1000Mb/s, VPN SafeStream

CODE: TL-ER6120 GIGA VPN ROUTER / EAN: 6935364041137

TP-Link TL-ER6120 | Router | 5x RJ45 1000Mb/s, VPN SafeStream

CODE: TL-ER6120 GIGA VPN ROUTER / EAN: 6935364041137
143,10 GBP without VAT (net)
Out of stock
Number of LAN ports: 4x 10/100/1000BaseTX (RJ45)
Number of WAN ports: 1x 10/100/1000BaseTX (RJ45)
3G/4G USB modem compatibility: No
AC input frequency: 50 - 60
Show more parameters

About product

TL-ER6120 SafeStream from TP-LINK - efficient and secure network

TL-ER6120 SafeStream TP-LINK has excellent data processing capabilities and many advanced features such as IPsec/PPTP/L2TP VPN, Load Balance, Access Control, IM/P2P Blocking, DoS Defense, Bandwidth Control, Session Limit, PPPoE Server that will meet the needs of small and medium-sized businesses, hotels, and communities with large numbers of users requiring an efficient and easy to manage network with high levels of security.

safestream vpn data protection gigabit dua-wan router er6120

Powerful router with VPN at the highest level

Router TL-ER6120 supports multiple VPN protocols, such as IPsec, PPTP and L2TP, in client/server modes. The device guarantees hardware support for VPN connections, with the ability to maintain up to 100 LAN-to-LAN/Client-to-LAN IPsec VPN connections. Moreover, the router uses DES/3DES/AES128/AES192/AES256 encryption, MD5/SHA1 authentication and two negotiation modes, i.e. Main/Aggressive modes. A 64-bit network processor and 512MB of DDR3 memory make the TL-ER6120 capable of handling many activities simultaneously, while maintaining excellent performance and stability of offered connections.

Universal router with intelligent bandwidth load balancing system

The TL-ER6120 router has been equipped with one WAN port and 3 WAN/LAN ports, making it a universal multitasker. It has a intelligent bandwidth load balancing system, which can separate the transmitted data according to the link parameters of each WAN port in order to use the total available transfer accordingly. Administrators have the ability to optimize the network with IP-based bandwidth control and by limiting the number of sections. Advanced surge protection protects TP-Link Gigabit router, it is fully resistant to the effects of lightning discharges up to 4 Kv. The router is also a safe solution in industrial networks, protecting computer networks against the effects of large voltage spikes.

Specification

Features / filters
Number of LAN ports 4x 10/100/1000BaseTX (RJ45)
Number of WAN ports 1x 10/100/1000BaseTX (RJ45)
3G/4G USB modem compatibility No
AC input frequency 50 - 60
AC input voltage 100 - 240
ARP attack prevention Yes
Built-in modem None
Cables included AC
Cabling technology 10/100/1000Base-T(X)
Certification CE, FCC
Data transfer rate 1000
DC-in jack Yes
Depth 180
DHCP client Yes
DHCP server Yes
DMZ support Yes
DoS attack prevention Yes
DSL WAN Yes
Ethernet interface type Gigabit Ethernet
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 5
Ethernet LAN data rates 10,100,1000
Ethernet WAN Yes
Firewall Yes
Flash memory 32
Height 44
Internal memory 512
Internal memory type DRAM
LED indicators Activity, Link, Power, System
Linux operating systems supported Yes
MAC address filtering Yes
Mac operating systems supported macOS
Management By web browser
Management protocols Telnet
Multicast support Yes
Network address translation (NAT) Yes
Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3u
Operating relative humidity (H-H) 10 - 90
Operating temperature (T-T) 0 - 40
Package depth 250
Package height 80
Package weight 2.28
Package width 528
Policy-based routing Yes
Power source type AC
Product colour Black
Rack capacity 1U
Rack mounting Yes
RAM memory 512MB
Reset button Yes
Security algorithms 3DES,128-bit AES,192-bit AES,256-bit AES,DES,MD5,SHA-1
SIM card slot No
Static route Yes
Storage relative humidity (H-H) 5 - 90
Storage temperature (T-T) -40 - 70
Supported network protocols TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
Supported protocols TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
Supported WAN type Static/Dynamic IP, PPPoE/Russian PPPoE, PPTP/Russian PPTP, L2TP/Russian L2TP, Bigpond Cable
Sustainability certificates RoHS
System event log Yes
Traffic control No
Type of case Metal
Type of device power supply Power supply
Universal Plug and Play (UPnP) Yes
URL filtering Yes
VLAN support Yes
Web-based management Yes
Width 440
Windows operating systems supported Windows 10,Windows 2000,Windows 7,Windows 8,Windows 8.1,Windows 98SE,Windows NT,Windows Vista,Windows XP

Equipment features
Standards and protocols IEEE 802.3, IEEE802.3u, IEEE802.3ab
TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
Ports 1 Gigabit WAN port
3 Gigabit WAN/LAN ports
1 Gigabit LAN port
Network cabling 10BASE-T: UTP cable cat. 3, 4, 5 (max. 100 m)
EIA/TIA-568 100 Ω STP (max. 100m)
100BASE-TX: Cat 5, 5e UTP cable (max. 100 m)
EIA/TIA-568 100 Ω STP (max. 100 m)
1000BASE-T: Cat 5, 5e, 6 UTP cable (max. 100 m)
Buttons Reset
Power supply Built-in universal power supply
AC100-240 V~ 50/60 Hz at input
Flash Memory 32 MB
DRAM memory DDR3 512 MB
LEDs PWR, SYS, Link/Act, Speed
Dimensions (S x G x W) 440 x 180 x 44 mm (17.3 x 7.1 x 1.7 inches)
Performance
Number of concurrent sessions 150000
NAT (iMIX) 936 Mb/s
NAT (DHCP) 878 Mb/s
NAT (PPPoE) 665 Mb/s
IPsec VPN Throughput (AES256) 373 Mb/s
Basic functions
WAN connection type Dynamic IP, static IP, PPPoE, PPTP, L2TP, BigPond
DHCP DHCP server/client
DHCP reservation
MAC address cloning MAC address cloning for WAN ports
IPTV Bridge mode, own
IPv6 IPv6 support
VLAN 802.1Q VLAN, VLAN port
Advanced features
IPsec VPN 100 IPsec VPN tunnels
LAN-to-LAN, Client-to-LAN
2 negotiation modes - Main/Aggressive
DES, 3DES, AES128, AES192, AES256 encryption
Authentication MD5, SHA1
IPsec NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)
PPTP VPN 50 PPTP VPN tunnels
PPTP VPN client/server
PPTP with MPPE encryption
L2TP VPN 50 L2TP VPN tunnels
Client/server L2TP VPN
L2TP over IPse
VPN Pass-through IPsec (ESP), PPTP, L2TP
Transmission security
Protection against network attacks Protection against TCP/UDP/ICMP Flood attacks
TCP scan blocking (Stealth FIN/Xmas/Null)
WAN-side ping blocking
Filtering Filtering of MAC addresses
Filtering URLs/keywords
Protection against ARP attacks Sending GARP packets
LAN/WAN side ARP scanning
IP-MAC address binding
Access Control Access control based on source/destination IP address
Services Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
Support Management via web interface
Remote management
Export/import configuration
SNMP
Diagnostics (Ping and Traceroute)
NTP synchronisation
System Log
Browser management Authentication of local users
Radius Server Authentication
Onekey Online
Other
Certificates CE, FCC, RoHS
Package contents TL-ER6120
Power supply
Assembly kit
Manual
System requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC® OS, NetWare®, UNIX® or Linux
Working environment Operating temperature: 0℃~40℃ (32℉~104℉)
Storage temperature: -40℃~70℃ (-40℉~158℉)
Operating humidity: 10%~90%, non-condensing
Storage humidity: 5%~90%, non-condensing

Support

Downloads:

Installation instructions Download
