Teltonika RUT360 | Industrial LTE Router | Cat.6, 1x LAN, 1x WAN 100Mb/s, WiFi 2,4GHz, RUT360 000000

CODE: TELTONIKA RUT360 000000 / EAN: 4779027312804

Teltonika RUT360 | Industrial LTE Router | Cat.6, 1x LAN, 1x WAN 100Mb/s, WiFi 2,4GHz, RUT360 000000

CODE: TELTONIKA RUT360 000000 / EAN: 4779027312804
130,82 GBP without VAT (net)
Any customs costs and VAT are to be borne by the buyer in the country of receipt.
Fast shipping
Antenna type: Internal
Antennas quantity: 4
Built-in processor: Yes
Data network: 3G, 4G
Show more parameters

About product

Teltonika RUT360

The RUT360 is an upgraded version of the bestselling RUT240. This compact industrial router offers cellular, Wi-Fi and wired Internet connectivity. The RUT360 features dual Ethernet interfaces, WiFi 802.11 b/g/n and a 4G LTE Cat 6 cellular module offering data rates up to 300 Mbps.

Unique programming, remote monitoring and security features make the RUT360 ideal for IoT and M2M applications where secure and reliable connectivity is a must. Carrier aggregation functionality makes this compact device indispensable in areas or applications where cellular data speeds are limited.

Wireless network

With built-in WiFi connectivity, you can take advantage of LTE with Wi-Fi operating at 2.4GHz.

External SIM card slot

SIM card slot allows you to easily install a SIM card in the router. After mounting the SIM card, the device will connect to the network and the device will not have to restart. Configuration of LTE connection is limited to entering APN name and PIN number of SIM card.

Two Ethernet ports

This small and compact device has two 10/100Mbps ports. The ports can be used as main internet connection or backup connection.

Teltonika RUT360 rms

Teltonika RMS

Teltonika Networks'Remote Management System (RMS) gives you control over your connected solution and consists of three main parts:

  • RMS MANAGEMENT - gives you full control over your fleet of Teltonika Networks routers and gateways, ensuring their security and availability.
  • RMS CONNECT - allows you to remotely access and control other smart devices, even without a public IP.
  • RMS API - helps you take what you need from RMS and deploy it to the IoT platform of your choice.

Specification

Features / filters
Antenna type Internal
Antennas quantity 4
Built-in processor Yes
Data network 3G, 4G
Depth 85
Device type Cellular network router
DHCP client Yes
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 2
Ethernet LAN data rates 10,100
Firewall Yes
Height 30
Housing material Aluminium
IP address filtering Yes
IP routing Yes
LED indicators LAN, Speed, WLAN
Networking standards IEEE 802.3, IEEE 802.3u
Number of SIM cards 1
Operating relative humidity (H-H) 10 - 90
Operating temperature (T-T) -40 - 75
Port forwarding Yes
Power consumption (typical) 10.5
Power source type DC
Processor frequency 0.65
Processor manufacturer Qualcomm
Processor model QCA9531
Product colour Silver
RAM capacity 0.128
RAM type LPDDR2
Reset button Yes
Security algorithms IPSEC, IPSec
Short Message Service (SMS) Yes
SIM card type MiniSIM
SIM interface 1.8
SMS cell broadcast Yes
Supported network protocols TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL)
URL filtering Yes
VPN support DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
Web-based management Yes
Weight 247
Wi-Fi Yes
Wi-Fi standards 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Width 100

Mobile network
Mobile module 4G (LTE) - Cat 6 up to 300 Mbps, 3G - up to 42 Mbps
Status Signal Strength (RSSI), SINR, RSRP, RSRQ, bytes sent/received,
combined bandwidth, aggregation, IMSI, ICCID
SMS SMS status, SMS configuration, sending/reading SMS via HTTP POST/GET,
EMAIL to SMS, SMS to E-MAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreplay
USSD Support for sending and reading USSD messages
Multiple DAPs Ability to use different PDNs to access multiple networks and services
Bandwidth management Band lock, display of bandwidth status in use
APN Auto APN
Wireless networks
Bridge mode Direct connection (bridge) between mobile ISP and device in LAN
Wireless mode 802.11 b/g/n, 2x2 MIMO, Access Point (AP), Station (STA)
Wi-Fi security WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK,
WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation
ESSID ESSID stealth mode
Hotspot Captive portal (Hotspot), internal/external Radius server,
embedded in a configurable landing page
Ethernet
WAN 1 x WAN (can be configured for LAN) 10/100 Mbps,
IEEE 802.3, IEEE 802.3u compliant, supports AUTO MDI/MDIX
LAN 1 x LAN port, 10/100 Mbps, IEEE 802.3, IEEE 802.3u compliant
automatic MDI/MDIX support
Network
Routing Static routing, dynamic routing (planned)
Network protocols TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP (planned),
SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP,
Telnet client, SNMP (planned), MQTT (planned), Wake on LAN (WOL) (planned)
VoIP passthrough support H.323 and SIP-alg protocol NAT helpers enabling proper
forwarding of VoIP packets
Call monitoring Ping Reboot, Periodic Reboot, LCP and ICMP for connection control
Firewall Port forwarding, network traffic rules, custom rules
DHCP Static and dynamic IP allocation, DHCP relayd
QoS Traffic prioritization by source/destination,
service, protocol or port, WMM, 802.11e
DDNS (planned) >25 service providers supported, others can be configured manually
Network backup Mobile, wired, Wi-Fi, all of which can be used as backup,
using automatic failover
Load balancing Balancing Internet traffic across multiple WAN connections
SSHFS (optional) Possibility of mounting a remote file system via SSH protocol
(not available in standard software)
Security
Authentication Shared key, digital certificates, X.509 certificates
Firewall Pre-configured firewall rules can be enabled via web-ui,
unlimited firewall configuration via CLI, DMZ, NAT, NAT-T
Prevention of attacks DDOS prevention (SYN protection, SSH attack prevention, HTTP/HTTPS attack prevention),
Port scanning prevention
(SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
VLAN Tag-based VLAN separation
Limiting Custom data limits for SIM card
WEB Filter A blacklist for blocking unwanted websites,
White list for determining allowed sites
Access control Flexible access control for TCP, UDP, ICMP packets, MAC address filters
VPN
OpenVPN Ability to run multiple clients and servers simultaneously, 12 encryption methods
OpenVPN encryption DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC,
CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
IPsec IKEv1, IKEv2, with 5 encryption methods (DES, 3DES, AES128, AES192, AES256)
GRE GRE Tunnel
PPTP, L2TP Client/server services can be started simultaneously,
L2TPv3 support (in plans)
Stunnel (planned) Proxy for adding TLS encryption functionality
to existing clients and servers without changing the program code
SSTP (planned) SSTP client instance support
DMVPN (in plans) A method for building scalable IPsec VPN networks
ZeroTier ZeroTier VPN Customer Support
WireGuard WireGuard VPN client and server support
Modbus TCP Slave (in plan)
ID filtering Response to one identifier in the range [1;255] or any
Allow remote access Allow access over WAN
Non-standard registers Modbus TCP custom register block that allows to read/write
to a file inside the router, and can be used to extend the Modbus TCP slave functionality.
Modbus TCP Master (in plan)
Supported functions 01, 02, 03, 04, 05, 06, 15, 16
Supported data formats 8 bit: INT, UINT; 16 bit: INT, UINT (MSB or LSB first);
32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian),
CDAB, BADC), HEX, ASCII
MQTT Gateway (in plan)
Gateway Enables sending commands and receiving data
from Modbus Master via MQTT broker.
Data to Server (planned)
Protocols HTTP(S), MQTT, Azure MQTT, Kinesis
Monitoring and management
WEB UI HTTP/HTTTPS, status, configuration, FW update, CLI,
troubleshooting, event log, system log, kernel log
FOTA Remote firmware update from server,
SSH (v1, v2)automatic notifications
SSH SSH (v1, v2)
SMS SMS status, SMS configuration, sending/reading SMS via HTTP POST/GET
Call Reboot, Status, Mobile data on/off, Output on/off
MQTT (in plan) MQTT Broker, MQTT publisher
SNMP (in plan) SNMP (v1, v2, v3), SNMP trap
JSON-RPC API management over HTTP/HTTPS
MODBUS (in plan) MODBUS TCP status/control
RMS Teltonika Remote Management System (RMS)
IoT platforms
Clouds of things Allows monitoring of: Device data, Mobile data, Network information, Availability
Cumulocity Allows you to monitor: Device model, revision and serial number,
Mobile Cell ID, ICCID, IMEI, connection type, carrier, signal strength, WAN and IP network type.
ThingWorx You can monitor: WAN Type, WAN IP,
Mobile Operator Name, Mobile Network Signal Strength, Mobile Network Type.
Azure IoT Hub Can send device IP, Number of bytes sent/received, Cellular connection status,
Network connection status, IMEI, ICCID, Model, Manufacturer, Serial, Revision, IMSI, SIM status,
PIN status, GSM signal, WCDMA RSCP, WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ, CELL ID,
Operator, Operator Number, Connection Type, Temperature, Azure IoT Hub PIN
System parameters
RAM 128 MB, DDR2
CPU QCA9531, MIPS 24kc, 650 MHz
Software/Configuration
Flash Memory 16 MB, SPI Flash (optionally up to 256 MB)
WEB UI Update software from file, check software on server,
configuration profiles, configuration backup, restore point
FOTA Software update/configuration from server
RMS Software/configuration update for multiple devices
Save settings Software update without losing current configuration
Inputs/Outputs
Configurable inputs/outputs 2 x Configurable digital inputs/outputs. Digital input 0 - 6 V detected as logic low,
8 - 30 V detected as logic high. Open collector output, max. output voltage 30 V, 300 mA
Event handling SMS, Email, RMS
Power supply
Connector 4-pin industrial DC power connector
Input voltage range 9-30 VDC reverse polarity protection, surge protection
Power consumption 10.5 W max.
Physical interfaces (ports, LED, antennas, buttons, SIM)
Ethernet 2 x RJ-45, 10/100 Mbps
LEDs 2 x Cellular connection type,
3 x Cellular connection strength,
2 x Eth Status,
1 x Power supply
SIM 1 x SIM socket (mini-SIM), 1.8 V/3 V, external SIM tray
Antennas 2 x SMA for LTE, 2 x RP-SMA for Wi-Fi antenna
Power supply 1 x 4 pin DC
Reset Buttons for restarting/restoring factory settings
Physical characteristics
Housing material Aluminium housing with DIN rail mounting option
Dimensions 100 x 30 x 85 mm
Weight 247 g
Mounting options DIN rail
Work environment
Operating temperature From -40°C to 75°C
Operating humidity 10% to 90%, non-condensing
