Extralink Minos | Outdoor PoE switch | 8x RJ45 1000Mbps PoE, 2x SFP, 200W, L2, active cooling

CODE: EX.32794 / EAN: 5905090332794

Extralink Minos | Outdoor PoE switch | 8x RJ45 1000Mbps PoE, 2x SFP, 200W, L2, active cooling

CODE: EX.32794 / EAN: 5905090332794
241,55 GBP without VAT (net)
Out of stock
10G support: No
AC input voltage: 100 - 240
Active link detection: Yes
Basic switching RJ-45 Ethernet ports quantity: 8
Show more parameters

About product

Extralink Minos - the ideal solution for an outdoor network

If you need a reliable and efficient network connection outdoors, the Extralink Minos Managed L2 Switch is the perfect choice for you. It includes 8 10/100/1000Mbps ports with PoE (downlink) and 2 1000Mbps SFP (uplink) ports to provide you with a stable and fast connection. Extralink Atlas is the ideal solution for monitoring buildings, roads, forests and extending network coverage. Get a stable and reliable network connection outdoors with Extralink Minos.

EXTRALINK MINOS OUTDOOR POE SWITCH batna24

Key features of Extralink Minos:

Gigabit ports with PoE power supply

With 8 10/100/1000Mbps PoE-enabled ports and 2 1000Mbps SFP uplink ports, Extralink Minos provides a stable and fast network connection outdoors. The power of 2 ports of 90W and 6 ports of 30W each, as well as the maximum power of the entire device of up to 200W, make it possible to connect devices that require PoE power.

EXTRALINK MINOS OUTDOOR POE SWITCH batna24

VLAN and PoE Auto-check

The VLAN mode provides port isolation from 1 to 8, allowing secure and stable communication only with uplink ports. The Extralink Atlas is also equipped with a PoE Auto-check function, which will check if connected devices are working properly and restart them if there is no response.

High level of surge and weather protection

The safety of your network is guaranteed by overvoltage protection of 6KV and ESD protection of 6KV (contact) and ESD 8KV (air). The device is also waterproof (IP55 rating) and protected against corrosion, so it can be used outdoors for a long time.

EXTRALINK MINOS OUTDOOR POE SWITCH batna24

Ideal switch for outdoor deployments

Extralink Minos is the perfect solution for those who need a reliable and stable network connection outdoors, in the field or in other places where PoE-powered network connectivity is required. Extralink Minos allows you to easily and cost-effectively deploy network solutions in places where access to power and stable and fast network connectivity is required. It will be perfect for such deployments as monitoring of buildings, roads, forests, production halls, parks and for extending network coverage.

Specification

Features / filters
10G support No
AC input voltage 100 - 240
Active link detection Yes
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Cable types supported Cat5e, Cat6
Depth 180
DHCP features DHCP client, DHCP relay, DHCP server
Ethernet LAN data rates 10,100,1000
Fiber optic connector LC
Gigabit Ethernet (copper) ports quantity 8
Height 260
Housing material Metal
IGMP snooping Yes
Installed SFP modules quantity 2
LED indicators Activity, Link, PoE
Loop protection Yes
MAC address filtering Yes
MAC address table 16384
Manual Yes
Networking standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z
Number of fans 1
Operating relative humidity (H-H) 0 - 95
Operating temperature (T-T) -20 - 65
Package type Box
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) power per port 30
Power over Ethernet (PoE) type supported Active PoE
Power source AC
Power supply included Yes
Product colour White
Quality of Service (QoS) support Yes
Rack mounting No
Redundant fans support Yes
Stackable No
Storage relative humidity (H-H) 0 - 95
Storage temperature (T-T) -40 - 85
Switch layer L2
Switch type Managed
Switching capacity 20
Throughput 14.88
Web-based management Yes
Weight 8
Width 200

Power supply
Power supply AC
Voltage AC100~240V, 50/60Hz
Energy consumption Without PoE <5W
With PoE 200W
Ethernet
Ports 8x RJ45 10/100/1000Base-T
2x 1G SFP
PoE ports ports 1 ~ 8, 802.3af/at,
port 1 ~ 2 90W
port 3 ~ 8 30W
Modes of operation Standard
VLAN
Recommended cable and distance cat5e/6, 100m
Switch
Standard IEEE802.3, IEEE802.3u, IEEE802.3z
Switch fabric 20 Gbps
Switching performance 14.88 Mpps
Buffer 1 M
MAC address table 8 K
LED signaling
Power supply 1x red LED
Uplink Green LEDs indicate connection/operation
Downlink Green LEDs indicate connection/operation
Yellow LEDs indicate PoE
Security
Surge 6KV, standard: IEC61000-4-5
ESD 6KV: contact / 8KV: air
standard: IEC61000-4-2
Environment
Operating temperature -20°C~65°C
Storage temperature -40°C~85°C
Moisture 0~95% (Non-condensing)
Physical parameters
Dimensions 280mm x 200mm x 260mm
Material Metal
Colour White
Net weight 8 kg
System configuration
System date and time SNTP (Web, CLI)
User management Adding, deleting (Web, CLI)
Secure management http (Web, CLI)
SNMP (Web, CLI)
telnet (CLI)
SSH (CLI)
Configuration file Upload, manage configuration files (Web, CLI)
Firmware Uploading firmware files (Web, CLI)
System Reboot (Web, CLI)
Reset to factory defaults (Web, CLI)
Port configuration
Admin status Up/Down (Web, CLI)
Capacity Full-1000 Mbps
Full-100 Mbps
Half-100 Mbps
Full-10 Mbps
Half-10 Mbps
Flow control On/Off (Web, CLI)
Limiting packet storms Block/Shutdown (Web, CLI).
