ZTE C300 as an OLT system offers plenty of space for expansion cards to build a high-speed network based on fiber optic cables and GPON/EPON technology. It provides high performance operation that will work well for "triple-play" uses: VoIP, IPTV and CATV.
The ZTE C300 platform has been created in a way that makes it possible to expand the network in the future. 21 slots for installing expansion cards provide enormous possibilities in building networks.
The main advantage of C300 is the unity of GPON/XGPON1 and P2P. Number of slots for additional modules significantly facilitates mass deployment of networks based on optical cables.
The C300 unit has these cards installed:
Switch / Control: 2 x SCXN Card (supports 16 GPON cards, 4 x GE Uplink ports, 2 x management interfaces)
GPON: 1 x GTGH Card (16 x GPON Port, 1:128 split ratio)
Uplink: 2 x GUFQ Card (4 x SFP (GE) ports)
Other cards: 2 x PRWG power supply cards
The ZTE C300 platform has redundant protection to minimize the risk of damage and network outages. Due to the dual power board, it is possible to replace a worn out module during operation. Supported protection types are B/C for the PON link and RSTP/UAPS/ERPS/LACP for the return link.
The C300 platform has received European CoC and RoHS certifications and ensures low power consumption, and through its ability to be further expanded it will remain in service longer thus reducing costs and saving resources.
TheC300 allows users high transmission speeds, access to multiple services and QoS support for stable operation, and support for applications such as HSI, VoIP, TDM, IPTV and mobile backhaul.
| Basic features | |
| Mounting plate capacities | 5.76 Tb/s |
| Switching capacity | 800 Gbps |
| Number of service cards slots | 14 (GPON / P2P / XG-PON1) |
| Number of control card slots | 2 |
| Number of power card slots | 2 |
| Number of Uplink card slots | 2 (10GE / GE / FE / E1 / T1) |
| Maximum number of GPON subscribers | 16 384 |
| Management interfaces | CLI, SSH, SNMP, telnet |
| Dimensions | 10U (443.7 x 482.6 x 270 mm) |
| Power supply | 48 V (DC) |
| Working conditions | Temperature: -25°C to 55°C Humidity: 5% to 95% |
| ITU G.984.x GPON Features | |
| Split ratio | 1:256 |
| Range | 20-60 km |
| Maximum attenuation | SFP B+ 28 dB SFP C+ 32 dB |
| Dynamic bandwidth allocation | NSR-DBA SR-DBA |
| Support | FEC AES128 SCB OLS |
| Features L2/L3 | |
| Routing | Static IPv4 and IPv6 |
| Multicast | IGMP Snooping/Proxy/SPR and MLD Snooping/Proxy 256 multicast VLANs CAC PRV CDR |
| QoS | 8 queues per port SP DWRR DSPC designation CIR PIR EIR |
| Security | L2-L4 ACL IP and MAC source guard DOS protection False MAC/IP protection Anti-flooding DHCP 82 |
| Additional parameters | VLAN, SVLAN, QinQ, VLAN Stacking, STP/RSTP/MSTP, DHCP Server, DHCP Relay, DHCP Proxy, Dual stack IPv4/IPv6 |
| Expansion card specifications | |
| Controls / Switches | 2 x SCXN card (support 16 GPON cards, 4 x Uplink GE interface, 2 x Management interface) 1 x GTGH card (16 x GPON port, 1:128 split ratio) |
| Uplink | 2 x GUFQ card (4 x SFP connector (GE)) |
| Other cards | 2 x PRWG power supply card |
You can search for expansion cards for the C300 platform on our store's website or in the manufacturer's general brochure, where they are described in more detail.
