Ubiquiti USW-LITE-16-POE | Switch | UniFi Gen2, 16x RJ45 1000Mb/s, 8x PoE+, 45W

CODE: USW-LITE-16-POE-EU / EAN: 0810010071163

Ubiquiti USW-LITE-16-POE | Switch | UniFi Gen2, 16x RJ45 1000Mb/s, 8x PoE+, 45W

CODE: USW-LITE-16-POE-EU / EAN: 0810010071163
182,63 GBP without VAT (net)
Number of LAN ports: 16x [10/100/1000M (RJ45)]
Number of PoE ports: 8x [802.3af/at (1G)]
10G support: No
Show more parameters
Number of LAN ports:
8x [10/100/1000M (RJ45)]
16x [10/100/1000M (RJ45)]

About product

16-port manageable Gigabit switch

UbiQuiti USW LITE-16-POE is a fully managed layer 2 switch with eight Gigabit Ethernet ports for RJ5 Ethernet devices. The switch also offers automatic 802.3at PoE + detection, which provides a total PoE power of 52 W for UniFi access points or other PoE devices. Switch with PoE power and PoE Passthrough function is ideal for cleanly adding Ethernet ports when needed with an adapter to power the PoE device.

UBIQUITI USW-LITE-8-

Non-blocking capacity

UbiQuiti USW-Lite-8-PoE switch is equipped with Gigabit Ethernet ports in a compact housing. The UnFi switch provides a total, non-blocking throughput of up to 8 Gb/s

UBIQUITI USW-LITE-8-POE

Switching capacity

The UniFi switch offers the ability to transmit traffic to all ports simultaneously at link speed without packet loss, with switching speeds up to 16 Gb/s.

Seamless integration

The installation of a cloud-based UniFi OS Console can be managed by multiple UnFi sites in one centralized interface. Each site is logically separated and has its own network monitoring, configurations, maps, statistics and administrator accounts.

Features:

  • 16 Gigabit RJ45 ports, including 8 ports 802.3at PoE +
  • Managed by the UniFi OS Console (5.13.10 or higher)
  • External 60 W power supply.
  • Mountable on the wall

Specification

Features / filters
LAN standard Gigabit Ethernet 10/100/1000 Mb/s
Number of LAN ports 16x [10/100/1000M (RJ45)]
Number of PoE ports 8x [802.3af/at (1G)]
10G support No
AC input voltage 100 - 240
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Certification CE, FCC, IC
Depth 185
Harmonized System (HS) code 85176990
Height 43.7
LED indicators Network, PoE, System
Management Dedicated application, By web browser,
Networking standards IEEE 802.3af,IEEE 802.3at
Number of power supply units 1
Operating relative humidity (H-H) 10 - 90
Operating temperature (T-T) -15 - 40
Power (W) 45
Power connector AC-in jack
Power consumption (max) 15
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 8
Power over Ethernet (PoE) power per port 30
Power supply included Yes
Product colour White
Switch layer L2
Switching capacity 16
Switching layer 2
Type of case Desktop
Wall mountable Yes
Weight 1.2
Width 191.7

Technical data
Dimensions 191.7 x 185 x 43.7 mm
Weight 1.2 kg
Max. Energy consumption 15W
Power supply method Universal AC input: 100-240VAC
Power supply Internal 60W AC/DC power supply
Network Interfaces 16 Ethernet ports RJ45 10/100/1000 Mb / s
PoE interfaces 8 PoE + IEEE 802.3af
Management interface Ethernet in the band
Max. PoE power 30W
Modes Gigabit Ethernet SMB Layer 2 PoE switch
Operating temperature -15 to 40 ° C
Operating moisture 10 - 90% non-condensing
Certificates CE, FCC, IC

Faq

How many PoE ports does UBIQUITI USW-LITE-16-POE have?

The device has 8 PoE+ ports

What is the maximum load per PoE port?

The maximum load per PoE port is 15.4W
