Ubiquiti US-24 | Switch | UniFi, 24x RJ45 1000Mb/s, 2x SFP
![](https://www.batna24.com/img2/1000/284186_1.webp?20989284238)
![](https://b2b.batna24.com/products/Logos/product/DNXFGKQUEKSJ.png)
EN
UniFi® US-24 switch by Ubiquiti is a fully managed gigabit switch. The device provides high performance with 24 independent switch ports and 2 SFP ports offering optical connectivity. The Unifi Switch line of devices is perfect for expanding as well as for building new computer networks.
The UniFi® US-24 switch integrates seamlessly with the UniFi Software-Defined Networking (SDN) platform, creating a highly scalable, comprehensive system of network devices in multiple locations - all controlled from one interface.
The UniFi US-24 switch can be placed on a shelf or mounted on a wall or in a Rack cabinet.
Features / filters | |
LAN standard | Gigabit Ethernet 10/100/1000 Mb/s |
Number of LAN ports | 24x [10/100/1000M (RJ45)] , 2x SFP (1,25G), |
10G support | No |
AC input frequency | 50/60 |
AC input voltage | 100 - 240 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Broadcast storm control | Yes |
Certification | CE, FCC, IC |
Combo SFP ports quantity | 2 |
Console port | RJ-45 |
Depth | 221 |
Ethernet LAN data rates | 10,100,1000 |
Flow control support | Yes |
Form factor | 1U |
Forwarding rate | 38.69 |
Full duplex | Yes |
Half duplex | Yes |
Harmonized System (HS) code | 85176990 |
Height | 43 |
Jumbo frames support | Yes |
LED indicators | Activity, Link, Speed |
Link aggregation | Yes |
Management | CLI - Command Line Interface, Dedicated application, |
Noise level | 37 |
Number of fans | 1 |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | -5 - 40 |
Port mirroring | Yes |
Power consumption (max) | 25 |
Power over Ethernet (PoE) | No |
Power supply included | Yes |
Product colour | White |
Quick start guide | Yes |
Rack mounting | Yes |
Reset button | Yes |
Security algorithms | 802.1x RADIUS |
Spanning tree protocol | Yes |
Switch layer | L2 |
Switch type | Managed |
Switching capacity | 52 |
Switching layer | 2 |
Type of case | Rack (1U), Metal, |
VLAN support | Yes |
Weight | 2.51 |
Width | 443 |
Basic technical parameters | |
Dimensions | 443 x 43 x 221 mm |
Weight | 2.60 kg |
Network Interfaces | 24 ports 10/100/1000 Mbps RJ45 Ethernet 2 ports 1 Gbps SFP Ethernet |
Management Interface | 1 RJ45 Serial Port Out-of-Band, Ethernet In-Band |
Non-blocking throughput | 26 Gbps |
Switching capacity | 52 Gbps |
Forwarding Rate | 38.69 Mpps |
Power supply method | 100-240V AC/50-60 Hz |
Power supply | AC/DC, internal, 25W DC |
Max. energy consumption | 25W |
LED lights | Speed/Link/Activity |
Noise level | Fan level 0: 34 dBa Fan level 1: 37 dBa |
ESD/EMP protection | Air: ± 24 kV, Contact: ± 24 kV |
Rack mount | Yes, 1U height |
Vibration resistance | ETSI300-019-1.4 Standard |
Operating temperature | -5 to 40° C (23 to 104° F) |
Operating humidity | 5 is 95% non-condensing |
Certificates | CE, FCC, IC |
Number of LAN ports 24x [10/100/1000M (RJ45)] , 2x [1G (SFP)] ,
Non-blocking throughput: 26 Gbps
Management through: CLI - Command Line Interface, Dedicated application,
