Ubiquiti UBB | Bridge | UniFi Building-to-Building, 60GHz, 5GHz, 1Gbps+, 1x RJ45 1000Mb/s

CODE: UBB-EU / EAN: 0817882029674

Ubiquiti UBB | Bridge | UniFi Building-to-Building, 60GHz, 5GHz, 1Gbps+, 1x RJ45 1000Mb/s

CODE: UBB-EU / EAN: 0817882029674
474,10 GBP without VAT (net)
Number of LAN ports: 1x 10/100/1000BaseTX (RJ45)
Antenna gain: 11dBi - 20dBi
Antenna gain level (max): 17.2
Certification: CE, FCC, IC
Show more parameters

About product

Wireless bridge | Building-to-Building

Bi-directional 60 GHz Plug and Play 1.7+ Gb/s bridge with 5 GHz radio redundancy, UniFi controller management and range up to 500m.

Installation and configuration in a few minutes

UniFi® Building-to-Building Bridge is the ideal solution for short range and high throughput connections. Integration with the UniFi OS Console makes bridging the two networks smooth. As a set of two UniFi Building-to-Building Bridge radios, the Bridge contains everything you need, so you can get started in just minutes. Enjoy simple, easy to use gigabit connectivity anywhere.

UBIQUITI UBB UNIFI BUILDING BRIDGE

The most important features:

  • Suitable for point-to-point WiFi connection
  • 60 GHz radio with a 5 GHz backup radio
  • Throughput up to 1.7 Gb/s
  • Transmission power 25 dBm (5 GHz)
  • Gain: 17.2 dBi (60 GHz), 10 dBi (5 GHz) and 2 dBi (2.4 GHz)
  • Managed by a UniFi network controller
  • Range up to 500 metres
  • PoE power supply
  • PoE 802.3af PoE or 48V PoE kit included
UBIQUITI UBB UNIFI BUILDING BRIDGE

Specification

Features / filters
Number of LAN ports 1x 10/100/1000BaseTX (RJ45)
Antenna gain 11dBi - 20dBi
Antenna gain level (max) 17.2
Certification CE, FCC, IC
Depth 140
Ethernet LAN Yes
Ethernet LAN data rates 10,100,1000
Ethernet LAN interface type Gigabit Ethernet
Frequency band 5.15 - 5.875, 57-66
Harmonized System (HS) code 85176990
Height 90
Material Polycarbonate
Networking standards IEEE 802.3af
Operating relative humidity (H-H) 5 - 95
Operating temperature (T-T) -40 - 60
Power consumption (max) 11
Power over Ethernet (PoE) Yes
Power source type PoE
Product colour White
Product type Network bridge
Quantity per pack 2
Signal strength 36.5
Weight 376
Width 140

Basic technical parameters:
Product code: UBB-EU
Dimensions 140 x 140 x 90 mm
Weight 376g
Antenna gain 2.4 GHz (BLE): 2 dBi
5 GHz: 10 dBi
60 GHz: 17.2 dBi
GPS Yes
Max. TX power 25 dBm (5 GHz)
Interfaces Network: (1) 10/100/1000
Ethernet port management : Bluetooth
Annex UV-resistant polycarbonate
Power supply method Supported
802.3af passive power supply via Ethernet (48 V)
Power supply UniFi PoE switch
48 V, 0.32 A Gigabit PoE Adapter (included)
Maximum energy consumption 11 W.
Wind load 56 N at 200 km / h (12.6 pounds at 125 mph)
Wind resistance 200 km / h (125 miles / h)
Installation Pole mount bracket (supplied)
Wall mounting bracket (not supplied)
ESD / EMP protection ± 24 kV Contact / air
Working temperature From -40 to 70 ° C (-40 to 158 ° F)
Working humidity 5 to 95% non-condensing
Certificates CE, FCC, IC
OPERATING FREQUENCY (MHZ)
Worldwide 5150 - 5875
57 000 - 66 000
US / CA U-NII-1: 5150 - 5250
U-NII-3: 5725 - 5850
57,000 - 66 000
The contents of the package: Bridge from building to UniFi building (x2)
Ball joint attachment (x2)
Security ring (x2)
Metal strap (x2)
Gigabit PoE (48 V, 0.32 A) with mounting bracket (x2)
Power supply cable (x2)

Support

Downloads:

Date sheet (ENG) Download
Quick Start (ENG) Download

Faq

Range?

500m

Power supply methods ?

Passive 802.3af power supply via Ethernet (48 V)

At what temperatures can the device operate ?

Operating temperature From -40 to 70 ° C
