Ubiquiti U6-Lite | Access point | UniFi 6 Lite, WiFi 6, MU-MIMO, 1x RJ45 1000Mb/s
![](https://www.batna24.com/img2/1000/329968_1.webp?20989284238)
![](https://b2b.batna24.com/products/Logos/product/DNXFGKQUEKSJ.png)
EN
UniFi 6 Lite Access Point is the latest WiFi 6 access point in the UniFi® series from Ubiquiti . It operates in the 2400-2483.5 MHz and 5150-5875 MHz frequency ranges, supporting the latest 802.11a/b/g/n/ac/ax wireless standards. The output power of the radio module is 23 dBm (depending on the country of use).
UniFi 6 Lite is the first 802.11a (Wi-Fi 6) access point with 2x2 antennas. UniFi 6 Lite supports innovative Wi-Fi 6 technology that enables a 29% increase in two-way wireless data rate and doubles the coverage area compared to the UniFi AC Lite access point. UniFi 6 Lite is able to provide a stable, high quality connection for more connected devices, MU-MIMO and OFDMA enable the most efficient use of bandwidth. UniFi 6 Lite exchanges data with different clients in parallel mode so it achieves minimal latency, the performance increase is especially noticeable in networks of different generations of Wi-Fi devices.
Use UniFi OS Console software to quickly configure and administrate your enterprise Wi-Fi network, and without any special training. Radio map, performance features, real-time status, automatic UAP device detection and advanced security options are already integrated.
Features / filters | |
LAN standard | Gigabit Ethernet 10/100/1000 Mb/s |
Maximum wireless transmission speed | 1200 Mb/s |
Number of LAN ports | 1x 10/100/1000BaseTX (RJ45) |
Operating frequency | Dual Band (2.4GHz, 5GHz) |
Wireless network standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, |
2.4 GHz | Yes |
5 GHz | Yes |
Antenna gain | Under 10dbi |
Antenna type | Integrated, Internal, |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 1000 |
Harmonized System (HS) code | 85176990 |
Maximum data transfer rate | 1500 |
Maximum data transfer rate (2.4 GHz) | 300 |
Maximum data transfer rate (5 GHz) | 1200 |
MIMO | Yes |
MIMO type | Multi User MIMO |
MIMO Type | 2x2, MU-MIMO 2x2, |
Networking standards | IEEE 802.3af |
Number of products included | 1 |
Placement | Ceiling, In-wall |
Power over Ethernet (PoE) | Yes |
Product colour | White |
Type of device power supply | PoE 802.3af, Passive PoE, |
Basic general data | |
Manufacturer | Ubiquiti |
Model | U6-Lite |
Model code | U6-LITE-EU |
Type | Access point |
Mechanical data | |
Dimensions | Ø160 x 32.65 mm (Ø6.3 x 1.3") |
Weight without attachment | 300 g (10.6 oz) |
Weight with mount | 315 g (11.1 oz) |
Housing characteristics | Polycarbonate 110 and ADC12 die-cast |
Mounting characteristics | Polycarbonate, SGCC steel |
Hardware specifications | |
Memory information | 256 MB |
Processor specifications | 880 MHz MIPS 1004 KEc |
Management interface | Ethernet In-Band |
Buttons | Factory reset |
Network interface | 1 x 10/100/1000 Mbps Ethernet RJ45 |
LEDs | White/Blue |
Power supply | 802.3af PoE; 48V, 0.32A PoE Adapter (not included) |
Supported voltage range | 44 to 57VDC |
Power supply method | 802.3af PoE, Passive PoE (48V) |
Max. power consumption | 12W |
MIMO | 2.4GHz - 2 x 2 5GHz - 2 x 2 |
Transmission speed | 2.4GHz - 300 Mb/s 5GHz - 1201 Mbps |
Max. TX power | 2.4GHz - 23 dBm 5GHz - 23 dBm |
Antenna gain | 2.4GHz - 2.8 dBi 5GHz - 3 dBi |
Operating temperature | -30 to 60° C (-22 to 140° F) |
Operating humidity | 5 - 95% non-condensing |
Certificates | CE, FCC, IC |
Software specifications | |
Wi-Fi standards | 802.11a/b/g Wi-Fi 4/Wi-Fi 5/Wi-Fi 6 |
Wireless network security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
VLAN | 802.1Q |
BSSID | 8 for each radio |
Advanced QoS | Speed limitation for individual users |
Isolation of visitor traffic | Supported |
Concurrent clients | 300 |
Supported data transfer rates (Mbps) | |
802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n (Wi-Fi 4) | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b | 1, 2, 5.5, 11 Mbps |
802.11ax (Wi-Fi 6) | 6.3 Mbps to 1.2 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80) |
802.11ac (Wi-Fi 5) | 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) |
Quick Installation Guide | Download |
The number of users depends on the CPU load. Ubiquiti recommends 20 ... 40 average users.
Lite means lightweight. It is not intended for use in areas of high client density. This item is not intended for parks or hotel lobbies. It is an office variant. Fast, reliable, secure. WiFi 6 supports the WPA3 standard, which is yet to be cracked. To address this issue, Ubiquiti has introduced the UniFi SHD Secure Access Point with a secure chip that is resistant to KRACK vulnerabilities.
The 2x2 antenna combination means that the data goes to 2x channels instead of 3x3 three channels. This does not always result in slower speeds.
Wifi6 802.11ax is backward compatible with all previous 802.11 AC, N, A, G standards except 802.11 B. Of course, with this compatibility, some features such as beamforming have been dropped.
