Ubiquiti BM2HP | CPE | Bullet M2 HP, 2,4GHz, 1x RJ45 100Mb/s

CODE: BULLETM2-HP / EAN: 0810354024900

Ubiquiti BM2HP | CPE | Bullet M2 HP, 2,4GHz, 1x RJ45 100Mb/s

CODE: BULLETM2-HP / EAN: 0810354024900
67,47 GBP without VAT (net)
Out of stock
2.4 GHz: Yes
Antenna connector type: N-type
Antenna features: Integrated antenna
Built-in processor: Yes
Show more parameters

About product

Fully integrated radio device

Pair Bullet M with any antenna to deploy airMAX in applications like PtP Bridging or PtMP. Its unique design increases link performance and reduces configuration complexity.

ubiquiti bullet m2hp 2,4GHZ 28DBM

Reliable throughput

Bullet M provides up to 100+ Mbps actual capacity.

BULLET M2HP 100mbps

Resistance for long-term outdoor use

The rugged, weather-resistant housing is resistant to the toughest outdoor conditions.

2,4GHZ 28DBM ubiquiti

Powerful performance

Bullet M has power up to 600 mW and an improved receiver design for PtP or PtMP applications.

600mW ubiquiti BULLET M2HP

Long-range connections

Bullet M provides high performance in a range up to 50+ km, depending on the antenna used.

50+ km ubiquiti bullet

Advanced software technology

Ubiquiti's airMAX technology has been proven in millions of devices worldwide, demonstrating exceptional performance in outdoor environments. The TDMA airMAX protocol provides exceptional scalability, high throughput and low latency in unlicensed, multipoint networks.

airmax ubiquiti

Plug and Play function

Connect Bullet M to any existing antenna with a female N-type connector to create a airMAX base station.

ubiquiti plug-and-play BULLET M2HP

Specification

Features / filters
2.4 GHz Yes
Antenna connector type N-type
Antenna features Integrated antenna
Built-in processor Yes
Certification ETSI300-019-1.4, FCC Part 15.247, IC RS210, CE, RoHS
Depth 152
Ethernet LAN (RJ-45) ports 1
Ethernet LAN data rates 10,100
Flash memory 8
Frequency band 2.4
Height 31
Housing material Plastic
Internal No
Internal memory 32
LED indicators Yes
Maximum data transfer rate 100
Maximum outdoor range 50000
Networking standards IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3u
Operating relative humidity (H-H) 5 - 95
Operating temperature (T-T) -20 - 70
Power consumption (max) 7
Power over Ethernet (PoE) Yes
Processor architecture MIPS 24Kc
Processor frequency 400
Processor model Qualcomm Atheros
Product colour White
Receiver sensitivity -96dBm +/-2dB
Supported network protocols TCP/IP
Transmitting power 28
Weight 180
Width 37

Basic technical parameters
CPU specification Atheros MIPS 24KC, 400MHz
Memory 32MB SDRAM, 8MB Flash
Network interface (1) 10/100 BASE-TX
Wireless approvals FCC Part 15.247, IC RS210, CE
RoHS compliance YES
Range efficiency Over 50 km
Radio connection N-type integrated male N-type socket (connected directly to the antenna)
Size case 15,2 × 3,7 × 3,1 cm
Weight 0.18 kg
Characteristics of the housing UV-stabilised plastic
Maximum power consumption 7 watts
Rated power Up to 24 V
Power supply method Passive PoE (pairs 4, 5+; 7, 8 return)
Operating temperature -40C to 80C
Working humidity 5 to 95%
Shocks and vibrations ETSI300-019-1.4

Support

Datasheet Download

Faq

What is the frequency of operation ?

Frequency of operation: 2.4 GHz

What is the LAN standard?

LAN standard: 10/100Mbps Fast Ethernet

What could be the operating temperature ?

Operating temperature from -40C to 80C
