MikroTik cAP ax | Access point | cAPGi-5HaxD2HaxD, Wi-Fi 6 AX1800, Dual Band, 2x RJ45 1000Mb/s, PoE
![](https://www.batna24.com/img2/1000/333675_163979.webp?20989284238)
EN
When it comes to wireless networking in the office, you can't afford to take shortcuts and risk lowering your team's productivity. You need excellent coverage throughout the facility. You need a device that can handle a large number of clients. You need a reliable, flexible and cost-effective solution: the MikroTik cAP ax Both open offices and cubicles usually suffer from various network problems: the signal is absorbed, reflected, becomes unstable. Mirrors, tinted glass, TVs, metal filing cabinets - all of these can interfere. The MikroTik cAP ax solution is simple, effective and elegant: let your access point rise above all obstacles! In other words, a ceiling-mounted access point is a great way to prevent signal loss in large, crowded areas with many obstacles.
There is another advantage to this design: the cAP ax remains hidden in plain sight, attracting less unwanted attention than a smoke detector. Your customers, visitors or co-workers won't even notice it. But they will definitely notice the incredibly fast wireless connection!
With the 6th generation 802.11ax wireless standard, we're looking at up to 40% faster speeds in the 5 GHz band and up to 90% faster speeds in the 2.4 GHz band when compared to previous generations! But more important than speed is stability. MikroTik's latest AX devices can withstand even the toughest wireless interference conditions, offering the most stable and uninterrupted signal yet!
MikroTik cAP ax features a state-of-the-art quad-core processor running at 1.8 GHz, NAND memory and a gigabyte of RAM. Enough to fully exploit the potential of the most powerful networking software on the market - RouterOS v7! Complex firewall rules, IPsec hardware encryption , Wireguard, BGP, advanced routing or multiple VPN tunnels for remote work - cAP ax can do it all!
Compared to the previous generation, the cAP ax offers many improved authentication types: OWE, WPA3-PSK, WPA3- EAP and 802.11r roaming.
The cAP ax is also a great way to simplify the installation and maintenance of your office network, as it has PoE-in and PoE-out. That's right - you can use the cAP ax to power other devices, such as network switches, CCTV cameras, or even another cAP ax! And speaking of easy office networking.... With just a few clicks on the latest wifiwave2 CAPsMAN central management system - and you can configure hundreds of cAP ax devices! You can use all kinds of MikroTik devices to effortlessly run CAPsMAN, for example - a master gateway.
Features / filters | |
2.4 GHz | Yes |
5 GHz | Yes |
AC adapter included | Yes |
Antenna type | Internal |
Built-in processor | Yes |
Cabling technology | 10/100/1000Base-T(X) |
Certification | CE, FCC, IC, EAC, ROHS |
DC voltage range | 18 - 57 |
DC-in jack | Yes |
Depth | 228 |
Ethernet LAN (RJ-45) ports | 2 |
Ethernet LAN data rates | 10,100,1000 |
Height | 48 |
Internal memory | 128 |
International Protection (IP) code | IP20 |
Maximum data transfer rate | 1774 |
Maximum data transfer rate (2.4 GHz) | 574 |
Maximum data transfer rate (5 GHz) | 1200 |
Mounting kit | Yes |
Number of products included | 1 |
Operating system installed | RouterOS |
Operating temperature (T-T) | -40 - 70 |
Output current | 0.4 |
Placement | Ceiling |
PoE adapter included | Yes |
Power consumption (max) | 28.2 |
Power over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) type supported | Passive PoE |
Processor model | IPQ-6010 |
Product colour | White |
Security algorithms | WPA3-EAP, WPA3-PSK |
Width | 228 |
Specification | |
Product code | cAPGi-5HaxD2HaxD |
Processor | ARM 64bit IPQ-6010 4 cores 864 - 1800 MHz |
RouterOS license | L4 |
Operating system | RouterOS v7 |
RAM | 1 GB |
Memory | 128 MB NAND |
MTBF | Approximately 200,000 hours at 25°C |
Operating temperature | -40°C to 70°C |
IPsec acceleration | Yes |
Wireless parameters | |
2.4 GHz wireless maximum data rate | 574 Mbps |
2.4 GHz wireless chain count | 2 |
2.4 GHz wireless standards | 802.11b/g/n/ax |
Antenna gain dBi for 2.4 GHz | 6 |
2.4 GHz wireless chip model | QCN-5022 |
2.4 GHz generation | Wi-Fi 6 |
Maximum 5 GHz wireless data rate | 1200 Mbit/s |
5 GHz wireless chain count | 2 |
5 GHz wireless standards | 802.11a/n/ac/ax |
Antenna gain dBi for 5 GHz | 5,5 |
5 GHz wireless chip model | QCN-5052 |
5 GHz generation | Wi-Fi 6 |
Wi-Fi speed | AX1800 |
Ethernet | |
10/100/1000 Ethernet Ports | 2 |
Number of 1G Ethernet ports with PoE-out functionality | 1 |
Power supply | |
Number of DC inputs | 2 (DC outlet, PoE-IN) |
DC outlet input voltage | 18-57 V |
Maximum power consumption | 28,2 W |
Maximum power consumption without attachments | 9 W |
Cooling type | Passive |
PoE input | 802.3af/at |
PoE input voltage | 18-57 V |
PoE output | |
PoE-out ports | Ether2 |
PoE output | Passive PoE up to 57 V |
Maximum current per output port (input 18-30 V) | 600 mA |
Maximum output power per port (input 30-57 V) | 400 mA |
Maximum total output current (A) | 600 mA |
Total output current | 0,4 |
Total output power | 19,2 |
Certification and approvals | |
Certification | CE, FCC, IC, EAC, ROHS |
IP | 20 |
