Cisco WAP121-E-K9-G5 | Access point | 150Mb/s, 1x RJ45 100Mb/s, PoE
![](https://www.batna24.com/img2/1000/104146_1.webp?20989284238)
EN
Increasingly, the workplace provides secure and fast wireless connectivity for employees and visitors, and this is more important than ever. The Cisco WAP12 Wireless-N access point with single point configuration is an easy and inexpensive way to increase the performance and coverage of a small business network with advanced 802.11n wireless technology. This flexible solution is ideal for connecting up to 10 employees in one access point. The wireless LAN can scale up to four WAP121 to provide wider coverage and support additional users as business needs change.
Designed for today's high-performance applications, Cisco WAP121 uses 802.11n wireless technology to provide high throughput and extended reach throughout the office. It has built-in (QoS) service quality features that allow bandwidth-sensitive traffic to be prioritized, enabling deployment of corporate voice quality over IP (VoIP) and video applications.
Cisco WAP121 is simple to set up and use, with an intuitive wizard-based configuration so you can start working in minutes. The elegant, compact design with flexible mounting options allows the access point to fit seamlessly into any small business environment. The PoE support makes it easy to install without the need for separate power plugs or expensive new cabling.
Features / filters | |
LAN standard | Fast Ethernet 10/100Mb/s |
Number of LAN ports | 1x 10/100BaseTX (RJ45) |
Operating frequency | 2.4 GHz |
Wireless network standards | IEEE 802.11n, IEEE 802.11b, IEEE 802.11g, |
2.4 GHz | Yes |
AC adapter included | Yes |
AC input voltage | 12 |
Access Control List (ACL) | Yes |
Antenna gain | Under 10dbi |
Antenna type | Integrated |
Antennas quantity | 4 |
Application | Indoor |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Cables included | LAN (RJ-45) |
Channels quantity | 13 |
DC-in jack | Yes |
Depth | 124.2 |
DHCP client | Yes |
DHCP server | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 10,100 |
Frequency band | 2.4 |
Height | 35 |
Input current | 0.5 |
Internal | No |
LED indicators | LAN, Power, WLAN |
MAC address filtering | Yes |
Management protocols | SNMP v.3 |
Networking standards | IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11i,IEEE 802.11n,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1x |
Number of users | 16 |
Operating relative humidity (H-H) | 10 - 85 |
Operating temperature (T-T) | 0 - 40 |
Power LED | Yes |
Power over Ethernet (PoE) | Yes |
Quality of Service (QoS) support | Yes |
Rack mounting | No |
Security algorithms | HTTPS,WEP,WPA,WPA2 |
Storage relative humidity (H-H) | 5 - 90 |
Storage temperature (T-T) | -20 - 70 |
Switch type | Managed |
Throughput data rate | 300 |
Type of device power supply | PoE 802.3af/at, Power supply, |
Weight | 168 |
Width | 124.2 |
Basic technical parameters: | |
Product code: | WAP121-E-K9-G5 |
Maximum data rate | 300 Mbit/s |
Frequency band | 2.4 GHz |
Number of channels | 16 |
Communication standards | IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x |
Management protocols | SNMP v.3 |
DHCP server | Yes |
CD output socket | Yes |
Number of Ethernet LAN ports (RJ-45) | 1x |
Encryption / security | WEP, WPA, WPA2 |
Physical security | HTTPS |
Method of authenticity | MAC ACL |
Cable lock socket | Kensington |
Service Quality Support (QoS) | Yes |
Product dimensions (SxGxW) | 124.17 x 124.17 x 35 mm |
Product weight | 168g |
Relative humidity range | 10 - 85 % |
Temperature range (operation) | 0 - 40 °C |
Temperature range (storage) | -20 - 70 °C |
Permissible relative humidity | 5 - 90 % |
Power supply | DC12V/0.5A |
PoE support | Yes |
Type of power supply | DC |
Frame mounting options | No |
Switch type | Managed |
LEDs | Link, Power, Status |
Power supply | Yes |
Power LED indicator | Yes |
Number of athens | 4 |
Detachable antenna(s) | No |
Temperature range (operation): 0 - 40 °C
Operating frequency: 2.4 GHz
Type of power supply of the device: PoE 802.3af/at, Power supply
