Cisco RV042 | Router | 4x RJ45 100Mb/s, 2x WAN, VPN

CODE: RV042-EU / EAN: 4260039342687

Cisco RV042 | Router | 4x RJ45 100Mb/s, 2x WAN, VPN

CODE: RV042-EU / EAN: 4260039342687
58,47 GBP without VAT (net)
Out of stock
Number of LAN ports: 4x 10/100BaseTX (RJ45)
Number of WAN ports: 2x 10/100BaseTX (RJ45)
Cabling technology: 10/100Base-T(X)
Connectivity LEDs: Yes
Show more parameters

About product

Cisco RV042 VPN Dual WAN Router - a reliable and secure network solution for small businesses.

Cisco RV042 Dual WAN VPN Router is an excellent choice for companies that value reliability and security. With support for two WAN connections, the device guarantees uninterrupted operation even in the event of failure of one of the providers, and simultaneous load balancing increases network performance. Advanced VPN features allow secure access to corporate resources from anywhere, making remote work safe and hassle-free. Simple configuration, a high level of business-grade security, and optional cloud-based Internet filtering make this router the ideal solution for any fast-growing business.

Cisco RV042 10/100 4-PORT VPN ROUTER

Dual WAN connection and advanced VPN features for maximum performance and business continuity

With the ability to use two WAN connections, the router balances the load, resulting in better network performance. When using different service providers, the device guarantees uninterrupted operation, even if one of the providers fails. Advanced VPN features allow secure access to corporate resources from anywhere, offering a level of security just like at the company's headquarters.

High level of security and simple configuration

The Cisco RV042 router offers business-class security features, and optional cloud-based Internet filtering further protects your network. The setup process is quick and easy with an intuitive browser-based interface and configuration wizards.
Typical configuration:

CISCO RV042 network configuration

Key features:

  • Two 10/100 Mb/s Fast Ethernet WAN ports for load balancing and/or business continuity
  • Built-in 4-port Fast Ethernet switch
  • Security - reliable firewall (SPI) and hardware encryption
  • High-performance VPN IP security features (IPsec)
  • Intuitive, browser-based device manager and configuration wizards
CISCO RV042 10/100 4-PORT VPN ROUTER

Specification

Features / filters
Number of LAN ports 4x 10/100BaseTX (RJ45)
Number of WAN ports 2x 10/100BaseTX (RJ45)
Cabling technology 10/100Base-T(X)
Connectivity LEDs Yes
Connectivity technology Wired
Data transfer rate 100
DC-in jack Yes
Depth 200
DHCP client Yes
DHCP server Yes
Dimensions (WxDxH) 130 x 200 x 39
Dual-band No
Ethernet interface type Fast Ethernet
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 4
Ethernet LAN data rates 10,100
Ethernet WAN Yes
Firewall security Stateful packet inspection (SPI) firewall
Full duplex Yes
Height 38.5
Management By web browser
Maximum data transfer rate 0.1
Networking features Fast Ethernet
Networking standards IEEE 802.3,IEEE 802.3u
Operating temperature (T-T) 0 - 40
Product colour Black, Silver
Quality of Service (QoS) support Yes
Security algorithms 128-bit AES,192-bit AES,256-bit AES,3DES,DES
Storage temperature (T-T) 0 - 70
Type of case Desktop
Type of device power supply Power supply
Web-based management Yes
Weight 576
Width 130

Technical specifications

Dual WAN Can be configured for Smartlink backup or load balancing
Standards ● 802.3, 802.3u
● IPv4 (RFC 791).
● Routing Information Protocol (RIP) v1 (RFC 1058) and v2 (RFC 1723).
Network protocols ● Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent.
● Static IP
● Point-to-Point Protocol over Ethernet (PPPoE).
● Point-to-Point Tunneling Protocol (PPTP).
● Transparent bridge
● DNS relay, Dynamic DNS (DynDNS, 3322).
Routing protocols ● Static
● RIP v1 and v2
Network Address Translation (NAT) ● Port address translation (PAT).
● Port network address translation (NAPT), NAT traversal, NAT one-to-one
Protocol binding Protocols can be associated with a specific WAN port for load balancing purposes
Network edge (DMZ) DMZ port, DMZ host
Security
Firewall SPI, Denial of Service (DoS), ping of death, SYN flood, land attack, IP spoofing, email alert for hacker attack
Access rules (access rules) Up to 50 entries
Port forwarding Up to 30 entries
Port triggering Up to 30 entries
Blocking Java, cookies, ActiveX, HTTP proxy
Content filtering Static URL blocking or keyword blocking
Secure management HTTPS, username/password, password complexity
VPN
IPsec 50 IPsec site-to-site tunnels for branch office connections
QuickVPN 50 QuickVPN tunnels for remote client access
PPTP 5 PPTP tunnels for remote access
Encryption Data encryption standard (DES), triple data encryption standard (3DES) and advanced encryption standard (AES)
AES-128, AES-192, AES-256
Authentication MD5/SHA1 authentication
IPsec NAT traversal Gateway-to-gateway and client-to-gateway tunnels are supported
VPN pass-through PPTP, L2TP, IPsec
Advanced VPN Dead peer detection (DPD), IKE, split DNS
Quality of Service (QoS)
Types of priorities Application-based priority on the WAN port
Service-based QoS Supports speed control or priority
Speed control Upstream/downstream, bandwidth can be configured for each service
Priority Each service can be assigned to one of 3 priority levels
Performance
NAT throughput 100 Mbps
IPsec VPN throughput 59 Mbps
Configuration
User Web Interface Simple browser-based device manager (HTTP/HTTPS)
Management
Management protocols Web browser, SNMP (Simple Network Management Protocol) v1 and v2c, Bonjour
Event registration Syslog, email alerts, VPN tunnel status monitor
Update Firmware update capability via web browser, imported/exported configuration file
Physical specification
Product dimensions (W x H x D) 130 mm x 38.5 mm x 200 mm
Ports 4 x 10/100 RJ45 LAN
1 x 10/100 RJ45 Internet port
1 x 10/100 RJ45 DMZ/Internet port
Power supply 12 V, 1 A
Certification FCC class B, CE Class B, cUL, Anatel, MEPS, CCC, PSB, CB, C-tick, KCC
Operating temperature 0°C to 40°C
Storage temperature 0°C to 70°C
Humidity during operation 10% to 85%, non-condensing
Storage humidity 5% to 90%, non-condensing
Cisco Limited Lifetime Warranty on Cisco Small Business Products This Cisco Small Business product comes with a limited lifetime hardware warranty, with a return-to-factory warranty, and a one-year limited warranty on fans and power supplies
Cisco offers free telephone technical support for the first 12 months from the date of purchase and any software bug fixes during the warranty period
For product warranty terms and other information on Cisco products, visit http://www.cisco.com/go/warranty

Support

Comparison of Cisco models of the RV0xx series - available at: Click here

Files to download

Datasheet - Datasheet (ENG) Download
Administration Guide (ENG) Download
