The Xiaomi AW300 camera is equipped with two built-in high-power white lights and two infrared lights, the device can capture full-color images even on the darkest night. The high-powered white lights will be automatically turned on when human motion is detected to capture full-color images.
The Xiaomi AW300 outdoor camera supports a smart electronic fence function. When it detects that the image changes or a human figure appears in a particular place, it will notify the owner by phone. The outdoor camera can sound an audible alarm with high-frequency flashing lights to ward off potential intruders.
You can watch live footage from multiple cameras simultaneously on devices such as TV, tablet and cell phone via the Mi Home/Xiaomi Home app. With the new generation of H.265 video encoding technology, the connection is more stable, smooth and lag-free.
With IP66 dust and water resistance, the outdoor camera works stably all year round in various weather conditions. Xiaomi AW300 has a special circuit design for the image sensor to reduce heat at high temperatures. The stable continuous operating temperature of Xiaomi AW 300 camera is from -30°C to 60°C.
Video recordings can be stored in various ways, so you don't have to worry about losing important video information. The Mi Home/Xiaomi Home app provides your devices with a cloud storage service for unusual events.
Features / filters | |
Antenna type | External |
Antennas quantity | 2 |
Auto focus | Yes |
Bluetooth | No |
Built-in HDD | No |
Built-in light | Yes |
Card reader integrated | Yes |
Compatible memory cards | MicroSD (TransFlash) |
Connectivity technology | Wireless |
Day/night mode | Yes |
DC output current | 1 |
DC output voltage | 12 |
Depth | 70 |
Detect distance | 25 |
Ethernet LAN | No |
Field of view (FOV) angle | 101.7 |
Form factor | Cube |
Height | 75 |
Infra-red wavelength | 850 |
International Protection (IP) code | IP66 |
LED indicators | Yes |
LED type | IR |
Live view | Yes |
Maximum memory card size | 256 |
Maximum resolution | 2304 x 1296 |
Minimum aperture number | 2 |
Mounting type | Ceiling/wall |
Night vision | Yes |
Number of cameras | 1 |
Number of illumination LEDs | 2 |
Number of lenses | 1 |
Operating temperature (T-T) | -30 - 60 |
Placement supported | Outdoor |
Power source type | DC |
Product colour | White |
Remote viewing | Yes |
Smartphone remote support | Yes |
Type | IP security camera |
Video formats supported | H.265 |
Weatherproof | Yes |
Web-based management | Yes |
Weight | 249 |
Wi-Fi | Yes |
Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Width | 173 |
Technical data | |
Rated input | 12V ⎓1A |
Dimensions | 173 × 70 × 75mm |
Weight | 249g |
Field of view (FoV) | 101,7° |
Resolution | 2304 × 1296 |
Hole | F2.0 |
Video codec | H.265 |
Night vision light | 850nm infrared light × 2 LED reflector × 2 |
Operating temperature | -30℃~60℃ |
Wireless connection | Wi-Fi IEEE 802.11b/g/n 2.4 GHz |
Storage function | MicroSD card (supported from 32 GB to 256 GB)/cloud storage |
