Ubiquiti UACC-OM-SM-10G-S-20 | SFP+ Module | BIDI, SM, Simplex LC, 10Gbps, 10km
CODE: UACC-OM-SM-10G-S-20 / EAN: 0810010076977
Contact
Account
Favorite
Cart
The Ubiquiti UACC-OM-SM-10G-S-20 10 Gbps Bidirectional Single-mode Optical Module is an SFP simplex module that provides speeds of up to 10 Gbps over distances of up to 10 kilometers.
| Features / filters | |
| Fiber optic connector | LC |
| Maximum data transfer rate | 10000 |
| Maximum operating temperature | 70 |
| Maximum transfer distance | 10000 |
| Number of products included | 20 |
| Numbers of pieces in the package | 20-pack |
| Operating temperature (T-T) | 0 - 70 |
| Product colour | Stainless steel |
| Rx wavelength (max) | 1330 |
| Rx wavelength (min) | 1270 |
| SFP transceiver type | Fiber optic |
| Single-mode fiber (SMF) supported | Yes |
| Tx wavelength (max) | 1330 |
| Tx wavelength (min) | 1270 |
| Technical data | |
| Media supported | Single-mode fiber |
| Connector type | (1) LC |
| BiDi | Yes |
| TX wavelength | Blue connector 1270 nm Red connector 1330 nm Must be used in pairs |
| RX wavelength | Blue connector 1270 nm Red connector 1330 nm Must be used in pairs |
| Data transmission speed | 10 Gbps |
| Max power consumption | 1W |
| Cable distance | 10km |
| Operating temperature | 0 to 70° C (32 to 158° F) |
| Packaging options | 2-pack, 20-pack |
| WARNING | CLASS 1 LASER PRODUCT, IEC/EN 60825-1:2014 - Do not look into the ends of the fiber optic cable or SFP module when the converters are powered up |
